10 MAX 860 1500 2500
All specications are subject to change without notice.
SPECIFICATIONS
MAX 860 Plus MAX 1500 Plus MAX 2500 Plus
Stereo Mode (driving both channels) Continuous Average Output Power Per Channel
8Ω EIA 1kHz 0.1%THD 200W 280W 500W
4Ω EIA 1kHz 0.1%THD 300W 450W 750W
Bridge Mono Mode Continuous Average Output Power
8Ω EIA 1kHz 0.1%THD 600W 900W 1500W
All Models
Output Circuitry Class H
Input Aensitivity @ 8Ω 1.23V (+4dBu)
Distortion (SMPTE-IM) <0.01% <0.02%
Noise (unweighted 20Hz-20KHz below
rated output)
100dB
Damping Factor >300 @ 8Ω
Frequency Response 20 Hz-20KHz, +0/-1dB; -3dB points: 5Hz-50KHz
Input Impedance 20 K Ω balanced, 10 K Ω unbalanced
Cooling Continuous variable-speed fan, front-to-rear air ow
Connectors (each channel) Input: XLR and 1/4” TRS; Output: Speakon and binding posts
Indicators Power: Blue LED; SIGNAL: Green LED; PEAK: Red LED
Controls
Front panel CH1 & CH2 GAIN knobs with 21 detents
Rear panel
Slide switches: Operation mode: Parallel, Bridge, Stereo;
Grounding/Floating; Current-Break reset button
Protection Circuitry
Short circuit, thermal, subsonic, RF protection,
Output DC offset, Power on/off muting
Power Consumption 600W 900W 1500W
Power Requirement (depends on region) 100~120VAC, 220~240VAC, 50/60Hz
Dimensions (WxHxD) 482.6 x 88 x 415mm (19” x 3.46” x 15.9”)
Weight 14.6kg (32.2 lbs)
