9
MU502 / MU802 / MU1002X
Maximum Level
Mic Preamp Input +10 dBu +10 dBu +10 dBu
AII Other inputs +22 dBu +22 dBu +22 dBu
Balanced Output +28 dBu +28 dBu +28 dBu
Impedance
Mic Preamp Input 2 K ohms 2 K ohms 2 K ohms
All Other Input (except insert) 10 K ohms 10 K ohms 10 K ohms
RCA 2T Output 1.1 K ohms 1.1 K ohms 1.1 K ohms
Equalization 2-band, +/-15 dB 3-band, +/-15 dB 3-band, +/-15 dB
Low EQ 80 Hz 80 Hz 80 Hz
Mid EQ - 2.5 KHz 2.5 KHz
Hi EQ 12 KHz 12 KHz 12 KHz
Low Cut Filter 75Hz (-18 dB/ oct) - 75Hz (-18 dB/ oct)
Power Requirement (external power sup-
ply, depends on region)
100VAC, 120VAC,
220~240VAC, 50/60Hz
100VAC, 120VAC,
220~240VAC, 50/60Hz
100VAC, 120VAC,
220~240VAC, 50/60Hz
Weight 1.1 kg (2.4 lbs) 1.5 kg (3.3 Ibs) 1.7 kg (3.74 Ibs)
Dimensions (WxHxD)
155.6 x 50.5 x 244 mm
(6.1” x 2” x 8.8”)
190 x 56 x 233 mm
(7.5” x 2.2” x 9.17”)
218 x 70 x 233 mm
(8.2” x 2.8” x 9.2”)
