SPECIFICATIONS
MU502 MU802 MU1002X
Inputs
Total Channels 3 4 6
Balanced Mono Mic/Line Channel 1 2 2
Balanced Stereo Line Channel 2 2 4
Aux Return - 1 stereo -
2T Input
Mini stereo and stereo
RCA
Mini stereo and stereo
RCA
Mini stereo and stereo RCA
Outputs
Main L/R Stereo 2x 1/4” TRS Bal. 2x1/4” TRS Bal. 2x1/4” TRS Bal.
Rec Out
Mini stereo and stereo
RCA
Mini stereo and stereo
RCA
Mini stereo and stereo RCA
CTRL RM L/R - 2 x 1/4” TS 2 x 1/4” TS
Phones 1 1 1
Channel Strips 3 4 6
EFX Send - 1 1
Pan/Balance Control Yes Yes Yes
Volume Control Rotary Rotary Rotary
lnserts 1 - -
Master Section
Phones Level Control Yes Yes Yes
Main L/R Level Control Rotary VR 60 mm fader 60 mm fader
Effect Processor - -
16 effects with one main
parameter control
Metering
Number of Channels 2 2 2
Segments 4 5 5
Phantom Power Supply +48V DC +48V DC +48V DC
Switches Master Master Master
Frequency Response (Mic input to any output)
20Hz - 60KHz +0/-1 dB +0/-1 dB +0/-1 dB
20Hz - 100KHz +0/-3 dB +0/-3 dB +0/-3 dB
Crosstalk (1KHz @ 0dBu, 20Hz to 20KHz bandwidth channel in to main L/R outputs)
Channel fader down, other channels at unity <-90 dB <-90 dB <-90 dB
Noise (20Hz - 20KHz; measured at main output，Channels 1-4 unit gain，EQ at; aII channels on main mix; channeIs 1/3 as far left
as possible, channels 2/4 as far right as possible. Reference=+6dBu)
Master @ unity, channel fader down -86.5 dBu -86.5 dBu -86.5 dBu
Master @ unity, channel fader @ unity -84 dBu -84 dBu -84 dBu
S/N ratio ref to +4 >90 dB >90 dB >90 dB
Microphone Preamp E.I.N
(150 ohms terminated, max gain)
<-129.5 dBm <-129.5 dBm <-129.5 dBm
THD (Any output, 1KHz @ +14dBu, 20Hz to
20KHz channel inputs)
<0 005% <0 005% <0 005%
CMRR (1 KHz @ -60dBu, gain at max.) 80 dB 80 dB 80 dB
