10 PM 801
SPECIFICATIONS
PM801
Inputs
Total Channels 8
Mic input / Line input 8 x XLR & 8 x 1/4”TS
Aux Bus In RCA
Outputs
Main Out 1/4” TS
Pre-Fader Out RCA
THD+N
THD (Any output, 1KHz @ +14dBu, 20Hz to 20KHz.)
0.01%
Metering
Channel Clip indicator +6 dBu
Phantom Power Supply +48V DC
Phantom Switches DIP
Frequency Response (Mic input to any output)
20Hz ~ 20KHz + 0/-1 dB
20Hz ~ 60KHz + 0/-3 dB
S/N ratio, ref to+4
106 dB
Microphone Preamp E.I.N. (150 ohms terminated, max gain) <-129.5 dBm
CMRR (1 KHz @ -60dBu, Gain at maximum ) 80 dB
Maximum Level
Mic Preamp Input +10 dBu
All Other Input +22 dBu
Main Output +22 dBu
Impedance
Mic Preamp Input 1.4 K ohms
Unbalanced Line in 12 K ohms
Aux bus in 10 K ohms
Main Output 100 ohms
Prefader Out 100 ohms
Power Requirement (depends on region, built-in) 100-120VAC,220-240 VAC, 50/60 Hz
Dimensions ( WxHxD ) 486x44x165mm (19”x1.75”x6.5”)
Net Weight 2.3 kg (5.07 lbs)
