INTRODUCTION
Thank you for choosing XP series power amplifier. The
unit
is designed to provide a good combination of
powe
r, audio clarity, reliability and durability. An effi-
cient
heat-dissipation system comprising a high-sur-
face
area heat sink coupled with two variable speed
fans
ensures quiet and reliable cooling. Good sound
quality
and sturdy construction make this unit ideal
for
a multitude of amplification tasks; from studio in-
stallations
to mobile DJs, house of worship and tour-
ing
bands. In order to get the best performance out of
your
XP series power amplifier, please read this user
’ s
manual carefully, and retain it for future reference.
FEATURES
Advanced powerful performance- third generation
circuitry
design
High continuous current output from robust
toroidel
transformer
Switchable input peak limiter and selectable high
pass
filter(30 Hz, 50 Hz) to reduce distortion and
protect
speakers
Front mounted 2 low pass filters (XP2100 and
XP31
00 only) and 2 gain-controls
Selectable stereo, parallel & bridge mono amp
mode
s
Ground Lift-switch against humming
Signal level at -40, -20, -10, protect and clip LED
indicators
to monitor performance
Bridge mono and parallel mode LEDs
Detented gain controls
Fast Recovery design for lower distortion if clipping
occurs
Active balanced inputs for low noise
XLR/TRS connectors for maximum input flexibility
Speakon and 5-way binding post speaker outputs
2 ventilation variable speed fans
Very rugged housing
fits a standard 19” rack
4
XP 600/1000/2000/2100/3000/3100

Phonic XP 3000 Specifications

General

Amplifier Type	Professional Power Amplifier
Number of Channels	2
THD	<0.03%
Signal-to-Noise Ratio	>100dB
Input Impedance	20 kOhms Balanced, 10 kOhms Unbalanced
Cooling	Variable speed fan
Connectors Input	XLR and 1/4" TRS
Power Output	3000W
Input Sensitivity	0.775V / 1.0V / 1.4V
Frequency Response	20Hz - 20kHz
Protection	Short Circuit, Thermal, Overload, DC Fault
Connectors Output	Speakon, Binding Post
Damping Factor	>300
