PHOTON Solar - 1 Getting Started; Verify Package Contents; Tools Required

4
A. Solar panel (Solar panel kit)
B. Battery pack / Receiver unit (Receiver Kit)
C. 3m power extension cable (Receiver kit)
D. Remote control (ordered separately)
E. Screws and brackets for Solar panel & screw caps
(Receiver kit)
1.2 Tools Required:
The general tools required when installing the solar powered awning motor are:
• Power drill & drill bits ( 3mm & 10mm)
• Phillips head screw driver
• Measuring/levelling tools
1. Getting Started
K
J
I
5m 10m
C.
D
B
A
E
H
F
G
F. Dry Contact Cable 30cm (Receiver kit)
G. 3.5mm mono to USB cable, 1m ((Receiver kit)
H. Cable clips with double sided tape (Receiver kit)
I. Crown & Drive wheel, 78mm (ordered separately)
J. Motor (Motor kit)
K. Extension cables 5m, 10m (order separately)
1.1 Verify Package Contents:
