LIFEPAK CR Plus and LIFEPAK EXPRESS Defibrillator Operating Instructions 1-7
©2009-2014 Physio-Control, Inc.
1 Introduction
Introduction
SYMBOLS
The following symbols may appear in this manual and on the LIFEPAK CR Plus and
LIFEPAK EXPRESS defibrillators. For more information about the readiness display symbols, refer to
Section 2, "Getting Started".
Symbol Explanation
OK Indicator. On the readiness display—the defibrillator is ready for use.
CHARGE-PAK battery charger indicator. On the readiness display—CHARGE-PAK
battery charger needs to be replaced.
Attention. On the readiness display—the internal battery is low. Refer to page 2-4 for
more information about the readiness display.
Wrench indicator. On the readiness display—there is a condition that prevents or
could prevent normal defibrillator operation. Refer to page 5-8 for more information.
On the CHARGE-PAK battery charger—consult the operating instructions. Refer to
page 5-2 for more information about the CHARGE-PAK battery charger.
On the back of the defibrillator—consult the operating instructions. Refer to page 1-5
for more information about the warnings and cautions.
On the electrode pads—consult the operating instructions. Refer to page 2-6 for more
information about electrode pads.
Warning, high voltage.
CHARGE-PAK battery charger.
This end up.
Fragile/breakable.
Handle with care.
Protect from water.
Power On/Off button.
Type BF patient connection.
