PIAGGIO Beverly 400 I.E User Manual

03_16
03_17
Checking the brake oil level (03_16, 03_17)
The brake fluid tanks of the front and rear brakes are located on the pumps under the
covers on the handlebar. Proceed as follows:
1. Place the scooter on its centre stand and make sure the handlebar is centred;
2. Remove cover "A" by removing the respective retaining screw "B";
3. Check the fluid level through the respective sight glass "C".
A certain lowering of the level is caused by wear on the pads. Should the level appear
to be below the minimum mark, please contact your nearest PIAGGIO Dealer or Au-
thorised Service Centre in order to have a thorough inspection of the brake system
carried out.
Braking system fluid top up
Proceed as follows:
Remove tank covers "A" and loosen the two screws and top up the brake fluid level
using only the prescribed brake fluid and without exceeding the maximum level.
Under normal climatic conditions, the brake fluid must be replaced every 20,000 km
or every two years, whichever comes first. This operation must be carried out by
trained technicians; please contact your nearest PIAGGIO Dealer or Authorised
Service Centre.
46
3 Maintenance

PIAGGIO Beverly 400 I.E Specifications

General

Engine Displacement	399 cc
Fuel System	Electronic Fuel Injection
Starter	Electric
Front Suspension	Telescopic hydraulic fork
Rear Brake	240 mm disc
ABS	Yes
Width	780 mm
Seat Height	790 mm
Fuel Tank Capacity	13 liters
Top Speed	140 km/h
Tires Rear	150/70-14
Engine Type	Single-cylinder, 4-stroke
Transmission	CVT
Rear Suspension	Double hydraulic shock absorber with adjustable preload
