03_18
03_19
Battery (03_18, 03_19)
To access the battery, proceed as follows:
1. Place the scooter on its centre stand;
2. Lift the seat, paying attention to the points mentioned above.
3. Remove retainer "A" and cover "B".
4. Release the elastic strap "C".
The battery is the electrical device that requires the most frequent inspections and
diligent maintenance.
The main points of maintenance to be observed are as follows:
WARNING
DO NOT DISCONNECT THE BATTERY CABLES WITH THE ENGINE RUNNING,
THIS CAN CAUSE PERMANENT DAMAGE TO THE VEHICLE ELECTRONIC CON-
TROL UNIT.
WARNING
THE ELECTROLYTE CONTAINS SULPHURIC ACID: AVOID CONTACT WITH
EYES, SKIN AND CLOTHES. IN THE CASE OF ACCIDENTAL CONTACT, RINSE
WITH ABUNDANT OF WATER AND CONSULT A DOCTOR.
WARNING
SPENT BATTERIES ARE HARMFUL FOR THE ENVIRONMENT. COLLECTION
AND DISPOSAL SHOULD BE CARRIED OUT IN COMPLIANCE WITH CURRENT
REGULATIONS.
48
