PIAGGIO MSS ZIP 100 4T User Manual

KEY
1. Electronic ignition device
2. Spark plug
3. Magneto flywheel
4. Voltage regulator
5. Main fuse
6. Key switch
7. Battery
8. Starter motor
9. Starter remote control
10. Starter button
11. Rear brake STOP button
12. Front brake STOP button
13. Horn button
14. Horn
15. Left rear turn indicator bulbs
16. Tail lights/stop light bulbs
17. Turn indicator switch
18. Right rear turn indicator bulbs
19. Left side headlight assembly
MSS ZIP 100 4T Electrical system
ELE SYS - 47
