PIAGGIO MSS ZIP 100 4T User Manual

A. Left front turn indicator bulb
B. Front position light bulb
20. Headlight assembly with high-/low-beam bulb
21. Right side headlight assembly
A. Left front turn indicator bulb
B. Front position light bulb
22. Light switch
23. Instrument panel
A. Turn indicator warning light
B. High-beam warning light
C. Low fuel warning light
D. Instrument panel bulb
E. Instrument panel bulb
24. Fuel level warning light control
25. Automatic starter
26. Resistance
Ar = Orange, Az = Sky Blue, Bi = White, Bl = Blue, Gi = Yellow, Gr = Grey, Ma = Brown, Ne = Black,
Ro = Pink, Rs = Red, Ve = Green, Vi = Purple
Conceptual diagrams
Electrical system MSS ZIP 100 4T
ELE SYS - 48
