PIAGGIO X8 250 i.e - Page 60

Fuse No. 3 Position on fuse holder: 3
Capacity: 15A
Protected circuits: Low Voltage
socket 12V-180W - Electrical fan
Starter - Actuators for opening
glove box and saddle with buttons
on the handlebar - Wiring for
antitheft device
Location:Battery compartment
(on LHS)
Fuse No. 4 Position on fuse holder: 4
Capacity: 10A
Protected circuits: High-voltage
coil - Injector - Fuel pump - Lambda
probe
Location:Battery compartment
(on LHS)
Fuse No. 5 Position on fuse holder: 5
Capacity: 10A
Protected circuits: Helmet
compartment lighting and its
telltale light - high-beam headlight
and its telltale light
Location:Battery compartment
(on LHS)
Fuse No. 6 Position on fuse holder: 6
Capacity: 3 A
Protected circuits: Injection ECU
60
3 Maintenance
