PIAGGIO X8 250 i.e - Page 61

Location:Battery compartment
(on LHS)
Fuse No. 7 Position on fuse holder: 7
Capacity: 7.5A
Protected circuits: Immobilizer
led, Clock, Pics
Location:Battery compartment
(on RHS)
Fuse No. 8 Position on fuse holder: 8
Capacity: 7.5A
Protected circuits: Turn
indicators, Saddle opening control
unit
Location:Battery compartment
(on RHS)
Fuse No. 9 Position on fuse holder: 9
Capacity: 7.5A
Protected circuits: Headlight,
stop light relay, Start up relay
Location:Battery compartment
(on RHS)
Fuse No. 10 Position on fuse holder: 10
Capacity: 7.5A
Protected circuits: Parking lights,
Front lights, Rear Lights, Licence
plate lighting, Horn, Low-beam
headlight in "Passing" function
61
3 Maintenance
