SECTION 7 - MAINTENANCE INFORMATION
Page 7.5
PXI/PXIe LVDT/RVDT/Resolver Simulator Module 41/43-670
pickering
Table 7.1 - Gain Verication Test Results For -xxxx01
Serial Number:
Channel
Number:
Date of Test:
Operator’s
Name:
Test Equipment
Used:
VSUM Measurement A Measurement B Minimum [VRMS] Maximum [VRMS]
Result (delete
as appropriate)
0.450 0.446 0.455 Pass / Fail
0.600 0.594 0.606 Pass / Fail
0.750 0.743 0.758 Pass / Fail
0.900 0.891 0.909 Pass / Fail
1.050 1.040 1.061 Pass / Fail
1.200 1.188 1.212 Pass / Fail
1.350 1.337 1.364 Pass / Fail
1.500 1.485 1.515 Pass / Fail
1.650 1.634 1.667 Pass / Fail
1.800 1.782 1.818 Pass / Fail
Note: The maximum and minimum values listed do not take into account test equipment uncertainty, values are provided for
convenience only. Only a high performance measuring device should be used to minimize the additional uncertainty.
Table 7.2 - Gain Verication Test Results For -xxxx02
Serial Number:
Channel
Number:
Date of Test:
Operator’s
Name:
Test Equipment
Used:
VSUM Measurement A Measurement B Minimum [VRMS] Maximum [VRMS]
Result (delete
as appropriate)
0.900 0.891 0.909 Pass / Fail
1.222 1.210 1.234 Pass / Fail
1.544 1.529 1.560 Pass / Fail
1.867 1.848 1.885 Pass / Fail
2.189 2.167 2.211 Pass / Fail
2.511 2.486 2.536 Pass / Fail
2.833 2.805 2.862 Pass / Fail
3.156 3.124 3.187 Pass / Fail
3.478 3.443 3.513 Pass / Fail
3.800 3.762 3.838 Pass / Fail
Note: The maximum and minimum values listed do not take into account test equipment uncertainty, values are provided for
convenience only. Only a high performance measuring device should be used to minimize the additional uncertainty.
