SECTION 7 - MAINTENANCE INFORMATION
PXI/PXIe LVDT/RVDT/Resolver Simulator Module 41/43-670
pickering
Table 7.3 - Gain Verication Test Results For -xxxx03
Serial Number:
Channel
Number:
Date of Test:
Operator’s
Name:
Test Equipment
Used:
VSUM Measurement A Measurement B Minimum [VRMS] Maximum [VRMS]
Result (delete
as appropriate)
1.800 1.782 1.818 Pass / Fail
2.456 2.431 2.480 Pass / Fail
3.111 3.080 3.142 Pass / Fail
3.767 3.729 3.804 Pass / Fail
4.422 4.378 4.466 Pass / Fail
5.078 5.027 5.129 Pass / Fail
5.733 5.676 5.791 Pass / Fail
6.389 6.325 6.453 Pass / Fail
7.044 6.974 7.115 Pass / Fail
7.700 7.623 7.777 Pass / Fail
Note: The maximum and minimum values listed do not take into account test equipment uncertainty, values are provided for
convenience only. Only a high performance measuring device should be used to minimize the additional uncertainty.
Table 7.4 - Gain Verication Test Results For -xxxx04
Serial Number:
Channel
Number:
Date of Test:
Operator’s
Name:
Test Equipment
Used:
VSUM Measurement A Measurement B Minimum [VRMS] Maximum [VRMS]
Result (delete
as appropriate)
3.500 3.465 3.535 Pass / Fail
4.833 4.785 4.882 Pass / Fail
6.167 6.105 6.228 Pass / Fail
7.500 7.425 7.575 Pass / Fail
8.833 8.745 8.922 Pass / Fail
10.167 10.065 10.268 Pass / Fail
11.500 11.385 11.615 Pass / Fail
12.833 12.705 12.962 Pass / Fail
14.167 14.025 14.308 Pass / Fail
15.500 15.345 15.655 Pass / Fail
Note: The maximum and minimum values listed do not take into account test equipment uncertainty, values are provided for
convenience only. Only a high performance measuring device should be used to minimize the additional uncertainty.
