SECTION 7 - MAINTENANCE INFORMATION
Page 7.7
PXI/PXIe LVDT/RVDT/Resolver Simulator Module 41/43-670
pickering
Table 7.5 - Gain Verication Test Results For -xxxx05
Serial Number:
Channel
Number:
Date of Test:
Operator’s
Name:
Test Equipment
Used:
VSUM Measurement A Measurement B Minimum [VRMS] Maximum [VRMS]
Result (delete
as appropriate)
7.000 6.930 7.070 Pass / Fail
9.667 9.570 9.763 Pass / Fail
12.333 12.210 12.457 Pass / Fail
15.000 14.850 15.150 Pass / Fail
17.667 17.490 17.843 Pass / Fail
20.333 20.130 20.537 Pass / Fail
23.000 22.770 23.230 Pass / Fail
25.667 25.410 25.923 Pass / Fail
28.333 28.050 28.617 Pass / Fail
31.000 30.690 31.310 Pass / Fail
Note: The maximum and minimum values listed do not take into account test equipment uncertainty, values are provided for
convenience only. Only a high performance measuring device should be used to minimize the additional uncertainty.
Table 7.6 - Linearity Verication Test Results For VDT Simulator
Serial Number:
Channel
Number:
Date of Test:
Operator’s
Name:
Test Equipment
Used:
Position Measured Position Minimum Maximum
Result (delete
as appropriate)
0.00 -0.10 0.10 Pass / Fail
11.11 11.01 11.21 Pass / Fail
22.22 22.12 22.32 Pass / Fail
33.33 33.23 33.43 Pass / Fail
44.44 44.34 44.54 Pass / Fail
55.56 55.46 55.66 Pass / Fail
66.67 66.57 66.77 Pass / Fail
77.78 77.68 77.88 Pass / Fail
88.89 88.79 88.99 Pass / Fail
100.00 99.90 100.10 Pass / Fail
Note: The maximum and minimum values listed do not take into account test equipment uncertainty, values are provided for
convenience only. Only a high performance measuring device should be used to minimize the additional uncertainty.
