JumpandFreezeusingtheoptionalE2RRemoteSwitch
To enable the JUMP and FREEZEfunctionsoftheRemote,poweruptheEcholution
2pedalwhileholdingtheENGAGE footswitch.
JUMPmodulatesthedelaylineoneoctaveeachdelaytimebydefault.Inorderto
accessotherintervalsorsetaseconddelayline,seethe‘PitchShifting’section.JUMPcan
betoggledwithouttheremoteswitchaswell(see‘TouchSwitches:DelayTimeRanges’)
FREEZEcreatesaloopoutofthematerialthatispresentinthedelayline.Thiscanbe
toggledonandoffbypressingtheFREEZEfootswitch.
WhenFREEZEisactive,theTapfootswitchbecomesLoopRecord.WhenFREEZEisturnedon,
pressingtheTAPfootswitchbeginrecordinganewloop.Asecondpress(within10seconds)
willclosetheloopandbeginplayback.Tooverdub,turnoffFREEZEtoaddnewmaterial
andturnFREEZEbackonwhendone.HittingtheTAPswitchwillclearanycurrentlylooped
audio.Torecordanewloop,makesureFREEZEisturnedonandthenhittheTAPfootswitch.
Once the JUMP and FREEZEremotefunctionsareenabled,theEcholution2will
rememberthispreferenceafteritispowereddown.TodisableJUMP and FREEZE
andrestorethepreferenceforinstantpresetaccess,simplypowerpoweruptheEcholution
2whileholdingtheENGAGE switch.
JUMP
Eachdelaytapcanbeassignedadifferentpitchshiftinterval.Thepitchshiftingcanbe
turnedonandoffatanypointusingtheremoteswitchJUMPfunctionorviaMIDI.
OnceapitchshiftvaluehasbeenselectedJUMPisautomaticallyenabled,sothatusers
withouttheremoteswitchcanenjoypitchshifteffects.Whenapitchshiftvaluehasbeen
selected,theJUMPfunction“latches”andtheJUMPswitchmustpressedagaintoturn
thepitchshiftingoff.PitchShiftvaluescanbeassigned,savedandrecalledinanyof
the 60 presets.
E2 REMOTE SWITCH
E2 REMOTE SWITCH
Tochangethepitchshiftvaluefortherstdelaytap,holddownboththeDelayTime
(Short/Med/Long)andTapsbuttonsandturnthePresetEncodertoselectthedesired
pitchshiftvalue.AftersimultaneouslypressingDelayTimeandTaps,(whileatleastone
ofthemisstillhelddown),the7-segmentdisplaywillshowanumberor“-“.Thisnumber
representsthePitchchange,Theintervalsaredisplayedasanumberanddecimalpoint;
eachnumberrepresentsacorrespondingscaledegree(5=perfectfth)withthedecimal
pointindicatingwhetherthatintervalisatted(5.=atve).
Thechangethepitchshiftvaluefortheseconddelaytap,holddowntheSpecialFX
(Pong/Halo)andTapsbuttonsandturnthepresetencoder.
TochangetheVOLUMEoftheseconddelaytap,holddowntheSpecialFX(Pong/Halo)and
Tapsbuttonsandturnthemixknob.
Whenonedelaytapisturnedonandapitchshiftvaluehasbeenselected,JUMPwithcause
thedelaytopitchshift.
Whenonedelaytapisturnedonandapitchshiftvaluehasbeenselectedforbothtaps,
JUMPwithcausethedelaytoalternatebetweenthetwoassignedpitches(FirstTappitchfor
onecycle,SecondTappitchforonecycle,etc).Thesecondtapwillnotbeheard.
Withtwodelaytapsturnedon,andapitchshiftvaluehasbeenselectedforonlyoneofthe
taps,onedelaywillpitchshiftandonewillnot.
Withtwodelaytapsturnedon,andapitchshiftvaluehasbeenselectedforbothsofthe
taps,eachdelaywillpitchshiftaccordingtotheselectedintervals.
WhenFREEZEisactivated,JUMPwillonlyremainactiveforasinglecycle,allowingmaterial
tochangepitchoneintervalatatime.
WhenFREEZEisactivatedwithasingletapbutapitchshiftvaluehasbeensetforbothtaps,
thepitchshiftvalueofthefrozendelaywillalternatewitheachpressoftheJUMPfootswitch.
