MIDI
EveryfunctionoftheEcholution2canbecontrolledviaMIDI.
SETTING THE E2 MIDI CHANNEL:
1. PoweruptheE2whileholdingdownthePRESETrotaryswitch.
2. After the rmware version number has been displayed, a ‘C’ will
 appear. This indicates that the E2 will enter the MIDI Channel
 SelectionMenuuponreleaseofthePresetrotaryswitch
3. Once in this menu, the user can see the current MIDI channel and
 changeit,ifnecessary,byturningthePresetRotarySwitch.
 *Possible MIDI Channels are 1-16, with tens indicated by an
 illuminateddecimalpoint,tothelowerrightofthenumber.
 i.e.9=9,0.=10,1.=11
4. To select a channel, PRESS the Preset rotary switch. The E2 will
continue its boot process.
SUPPORTED MIDI COMMANDS
Toloadaparticularpreset,simplysendaprogramchangecommandwiththedesired
presetnumber.TheE2willloadthatnumberplusoneasthepreset.Thisisbecause
manyMIDIcontrollerssend“PROGRAM CHANGEx-1”whenyouselect
programx.ie.Thefootcontrollerwillsend“PROGRAM CHANGE 00”
whenyouselectthefootswitchcorrespondingtopreset1.Ifyouwantpreset00,send
127astheprogram.
MIDI
MIDI CLOCK OPTIONS
Non-pitchedMIDITracking:TapsteleportwhenanewMIDITempoisreceived.The
newMIDIclockwillonlyjumpifthechangeintempoisgreaterthan10ms.Thiscan
beswitchedonandoffduringtheboot-upprocessbyholdingtheDelayTimebutton.
EnableMIDIClockIn:ThisallowstheE2toadjustitsdelaytimeinaccordancewitha
MIDIclockconnectedtotheMIDIINport.Byswitchingthisoff,theE2willignorethe
MIDIclockreceivedintheinputandreplacesitwithitsownclock.TotoggletheEnable
MIDIClocksetting,pressandholdEXPbuttonduringpowerup.
Note:WhenMIDISynced,tappinganewdelaylengthwillquantizethenewlengthto
anintegernumberofMIDIquarternotes.(i.e.youcanchangethedelaytimewhile
remainingMIDISynced).Togetbacktotheoriginaldelaytime,doubletaptheTap
Temposwitch.
EnableMIDIClockOut:ThisallowstheE2tooutputitsownMIDIclocktakenfromits
DelayTimeknobandpassitoutofitsMIDIOUTport.TotoggletheEnableMIDIClock
Outsetting,pressandholdSpecialFunctionsbuttonduringpowerup.
CopyMIDIClock:ThispassestheMIDIClockIn,totheMIDIClockOut.EveniftheE2is
ignoringtheMIDIClockInandoperatingonitsowndelaytime,itwillstilloutputthe
MIDIClockIn.ThisallowstheusertocontrolmultipleE2’sviaMIDICC’swithdifferent
delaylengths.TotoggletheCopyMIDIClocksetting,pressandholdSpecialEffects
buttonduringpowerup.
