Pilotfly H2 - Page 6

IM_208.CCF.20170508-EN
6
Product Overview
“Mode” button
The respective operating mode of your Pilotfly Gimbal can be set using the mode button. The mode button
can be assigned different profiles using the SimpleBGC software GUI.
A profile is respectively a set of predefined settings such as, for example, different provisions for the
following mode, the rotation speed of the individual axes, the initial alignment of the axes, time lapse
settings, axis acceleration, control parameters tuned to your camera weight for optimal vibration reduction,
parameters for smooth operation, etc.). You can optimize these settings according to your own preferences
using the SimpleBGC 32 Bit software GUI  5. Software use for PC/MAC or also using the applicable
SimpleBGC Apps for Android or iOS.
In the table you can see the pre-set assignment and a description of the settings stored as profile
respectively:
Key sequence
Function
Description
1 x press Follow mode
Profile 1
-
Camera follows the
movements.
2 x press Lock mode of pitch &
roll axis
Profile
2
-
Camera remains in the
horizon and follows still the horizontal
rotation.
3 x press Lock mode of all 3
axes
Profile
3
-
All three axes are locked.
Camera is kept in the adjusted
position.
4 x press Follow mode of all 3
axes
Profile
4
-
All three axes follow the
movements.
5 x press Starting point
„zero position“
Home Position
-
Camera returns to
"zero position" into the starting point.
Press and hold 3
seconds
Only supported with models
shipped before April 2017.
New models perform a gyro-
calibration directly during
switching on.
Activates the Gyro-
calibration
Calibrate Gyro
-
Avoid any
movements and vibrations during the
calibration.
Invert Turn the grip in the way that it is over
the camera. The new position is
recognized automatically.
All other above mentioned modes can
also be selcted in the inverted
condition.
