Pilz PNOZ 8 User Manual

PNOZ 8
Operating Manual PNOZ 8
22152-EN-05
| 19
Conventional thermal current
while loading several contacts
774760 774768
Ith per contact at UB DC;
AC1:240V,DC1:24V
Conv. therm. current with 1 con-
tact 8 A –
Conv. therm. current with 2 con-
tacts 8 A –
Conv. therm. current with 3 con-
tacts 7 A –
Times 774760 774768
Switch-on delay
Typ. switch-on delay 150 ms 150 ms
Max. switch-on delay 350 ms 350 ms
Delay-on de-energisation
With E-STOP typ. 15 ms 15 ms
With E-STOP max. 30 ms 30 ms
With power failure typ. 100 ms 100 ms
With power failure max. 200 ms 200 ms
Recovery time at max. switching
frequency 1/s
After E-STOP 300 ms 300 ms
Supply interruption before de-ener-
gisation 20 ms 20 ms
Fuse trigger delay 150 ms 350 ms
Environmental data 774760 774768
Climatic suitability EN 60068-2-78 EN 60068-2-78
Ambient temperature
Temperature range -10 - 55 °C -10 - 55 °C
Storage temperature
Temperature range -40 - 85 °C -40 - 85 °C
Climatic suitability
Humidity 93 % r. h. at 40 °C 93 % r. h. at 40 °C
Condensation during operation Not permitted Not permitted
EMC EN 60947-5-1, EN 61000-6-2, EN
61326-3-1
EN 60947-5-1, EN 61000-6-2, EN
61326-3-1
Vibration
In accordance with the standard EN 60068-2-6 EN 60068-2-6
Frequency 10 - 55 Hz 10 - 55 Hz
Amplitude 0,35 mm 0,35 mm
Airgap creepage
In accordance with the standard EN 60947-1 EN 60947-1
Overvoltage category III / II III / II
Pollution degree 2 2
Rated insulation voltage 250 V 250 V
Rated impulse withstand voltage 4 kV 4 kV
