PSEN cs4.1 M12/8-1.5m

Operating Manual PSEN cs4.1 M12/8-1.5m

1003810-EN-07

| 17

Connection diagram, single connection with SDD

S21S11

24 V 0 V

12 22

I2 (FS)I1 (FS)

FS: Failsafe

Y32

Rx Tx

Actuator

Safety switch

Evaluation device

Fieldbus module
