PSEN cs4.1 M12/8-1.5m
Operating Manual PSEN cs4.1 M12/8-1.5m
1003810-EN-07
| 24
Installation
General
CAUTION!
Potential loss of safety function due to changed device properties
The unit's properties may be affected if installed in an environment contain-
ing electrically or magnetically conductive material.
– Please check the operating distances and the assured release dis-
tance.
} The safety switch and actuator should be installed opposite each other in parallel.
} Torque setting: Please note the information provided under Technical details [ 35].
} The distance between two safety switches must be maintained (see Technical
details [ 35]).
} Make sure that the safety switch and actuator cannot be used as an end stop.
} Please note the installation measures in accordance with EN ISO 14119 for a safety
switch design 4 and with level of coding High.
} Please note the permitted bending radii for the cable (see Technical details [ 35]), to
avoid excessive force on the individual strands.
} Make sure that the bend protection is not damaged. Such damage can cause the whole
product to fail.
} For simpler installation, the mounting brackets (see Order reference for
Accessories [ 44]) can be used.
Safety switch
} Safety switches should only be secured using M4 screws with a flat head (e.g. M4
cheese-head or pan head screws).
Procedure:
1. Provide the mounting surface with two drill holes for fastening the safety switch (see
Dimensions [ 32]).
2. Use two screws to fix the safety switch in place. Do not fully tighten the 2nd screw on
the safety switch.
