PSEN cs4.1 M12/8-1.5m
Operating Manual PSEN cs4.1 M12/8-1.5m
1003810-EN-07
| 36
Times
Test pulse duration, safety outputs 450 µs
Switch-on delay
after UB is applied 1 s
Inputs typ. 13 ms
Inputs max. 20 ms
Actuator typ. 60 ms
Actuator max. 150 ms
Delay-on de-energisation
Inputs typ. 15 ms
Inputs max. 20 ms
Actuator typ. 40 ms
Actuator max. 260 ms
Risk time in accordance with EN 60947-5-3 260 ms
Supply interruption before de-energisation 10 ms
Simultaneity, channel 1 and 2 max. ∞
Environmental data
Ambient temperature
In accordance with the standard EN 60068-2-14
Temperature range -25 - 70 °C
Storage temperature
In accordance with the standard EN 60068-2-1/-2
Temperature range -25 - 70 °C
Climatic suitability
In accordance with the standard EN 60068-2-78
Humidity 93 % r. h. at 40 °C
EMC EN 60947-5-3
Vibration
In accordance with the standard EN 60947-5-2
Frequency 10 - 55 Hz
Amplitude 1 mm
Shock stress
In accordance with the standard EN 60947-5-2
Acceleration 30g
Duration 18 ms
Airgap creepage
Overvoltage category III
Pollution degree 3
Rated insulation voltage 75 V
Rated impulse withstand voltage 0,8 kV
Protection type
Housing IP6K9K
Connector IP67
