PSEN cs4.1 M12/8-1.5m
Operating Manual PSEN cs4.1 M12/8-1.5m
1003810-EN-07
| 40
Environmental data 541187 541188
Vibration
In accordance with the standard EN 60947-5-2 EN 60947-5-2
Frequency 10 - 55 Hz 10 - 55 Hz
Amplitude 1 mm 1 mm
Shock stress
In accordance with the standard EN 60947-5-2 EN 60947-5-2
Acceleration 30g 30g
Duration 11 ms 11 ms
Protection type
Housing IP67 IP67
Mechanical data 541187 541188
Material
Top PBT PBT
Max. torque setting for fixing
screws – 0,1 Nm
Dimensions
Height 3,8 mm 3,8 mm
Width 18 mm 18 mm
Depth 18 mm 18 mm
Weight 2 g 2 g
Where standards are undated, the 2016-10 latest editions shall apply.
