PSEN cs4.1 M12/8-1.5m
Operating Manual PSEN cs4.1 M12/8-1.5m
1003810-EN-07
| 38
Mechanical data
Sensor flush installation in accordance with EN
60947-5-2 yes, follow installation guidelines
Connection type M12, 8-pin male connector
Cable Li9Y11Y 8 x 0,14 mm2
Material
Top PBT
Max. torque setting for fixing screws 0,8 Nm
Dimensions
Height 37 mm
Width 26 mm
Depth 18 mm
Weight of safety switch 100 g
Where standards are undated, the 2016-10 latest editions shall apply.
Technical details actuator
Order no. 540180 - 541180
See below for more order numbers
General 540180 541180
Certifications
CE, TÜV, UKCA, cULus Listed
CE, EAC, TÜV, UKCA, cULus Lis-
ted
Sensor's mode of operation Transponder Transponder
Coding level in accordance with EN
ISO 14119 High High
Pilz coding type fully coded fully coded
Transponder 540180 541180
Frequency band 122 kHz - 128 kHz 122 kHz - 128 kHz
Environmental data 540180 541180
Ambient temperature
In accordance with the standard EN 60068-2-14 EN 60068-2-14
Temperature range -25 - 70 °C -25 - 70 °C
Storage temperature
In accordance with the standard EN 60068-2-1/-2 EN 60068-2-1/-2
Temperature range -40 - 85 °C -25 - 70 °C
Climatic suitability
In accordance with the standard EN 60068-2-78 EN 60068-2-78
Humidity 93 % r. h. at 40 °C 93 % r. h. at 40 °C
EMC EN 60947-5-3 EN 60947-5-3
Vibration
In accordance with the standard EN 60947-5-2 EN 60947-5-2
Frequency 10 - 55 Hz 10 - 55 Hz
Amplitude 1 mm 1 mm
