PSEN cs4.1 M12/8-1.5m
Operating Manual PSEN cs4.1 M12/8-1.5m
1003810-EN-07
| 37
Operating distances
Actuator 1
Type PSEN cs4.1
Assured operating distance Sao 8 mm
Typical operating distance So 11 mm
Assured release distance Sar 20 mm
Typical release distance Sr 14 mm
Repetition accuracy switching distances 10 %
Change of operating distance with temperature
changes +-0,01mm/°C
Typ. Hysteresis 2 mm
Actuator 2
Type PSEN cs2.1
Assured operating distance Sao 10 mm
Typical operating distance So 25 mm
Assured release distance Sar 33 mm
Typical release distance Sr 29 mm
Repetition accuracy switching distances 10 %
Change of operating distance with temperature
changes +-0,1mm/°C
Typ. Hysteresis 3 mm
Actuator 3
Type PSEN cs4.1 low profile glue
Assured operating distance Sao 5 mm
Typical operating distance So 10 mm
Assured release distance Sar 20 mm
Typical release distance Sr 12 mm
Repetition accuracy switching distances 10 %
Change of operating distance with temperature
changes +-0,01mm/°C
Typ. Hysteresis 2 mm
Actuator 4
Typ PSEN cs4.1 low profile screw
Assured operating distance Sao 5 mm
Typical operating distance So 10 mm
Assured release distance Sar 20 mm
Typical release distance Sr 12 mm
Repetition accuracy switching distances 10 %
Change of operating distance with temperature
changes +-0,01mm/°C
Typical hysteresis 2 mm
Mechanical data
Min. bending radius (fixed permanently) K1 5 x Ø
Min. bending radius (moving) K1 10 x Ø
Cable diameter K1 5,55 mm
Min. distance between safety switches 100 mm
