Series connection
Product type Connection X1 Connection X2 Connec-
tion X3
Order no.
PSEN Y junction M12
SENSOR
M12, 8‑pin, pin M12, 8-pin, socket M12, 8-
pin,
socket
540315
PSEN Y junction M12
cable channel
M12, 8‑pin, pin M12, 8-pin, socket M12, 8-
pin,
socket
540316
PSEN T junction M12 M12, 8-pin, socket M12, 8‑pin, pin M8,
4‑pin, pin
540331
PSEN Y junction M8-M12/
M12 PIGTAIL
M12, 8-pin, socket M12, 8‑pin, pin M8,
8‑pin,
socket
540337
PSEN Y junction M12-M12/
M12 PIGTAIL
M12, 8-pin, socket M12, 8‑pin, pin M12, 8-
pin,
socket
540338
PDP67 F 4 code Decentralised passive junction 773603
PDP67 F 4 code VA Decentralised passive junction, V2A ring nut 773613
Safety Device Diagnostics
Product type Features Connection type Order no.
PSENix2F4code Interface for connecting
max. 4 PSEN safety
sensors
Spring-loaded terminal 535111
PSENix2F8code Interface for connecting
max. 8 PSEN safety
sensors
Spring-loaded terminal 535112
SDD ES ETH Modbus/TCP fieldbus mod-
ule for Safety Device Dia-
gnostics
Spring-loaded terminal 540130
SDD ES Profibus Profibus fieldbus module
for Safety Device Dia-
gnostics
Spring-loaded terminal 540132
SDD ES Profinet Profinet fieldbus module for
Safety Device Diagnostics
Spring-loaded terminal 540138
