Operating Manual: PSS SB ACTIVE JUNCTION BASIS
Intended use
The PSS SB ACTIVE JUNCTION BASIS is designed for use in SafetyBUS p
networks. It is suitable for connecting physically remote field devices (e.g. light
guards) to the SafetyBUS p main branch. Using the unit allows you to build a star
or tree structure, rather than the linear topology specified for SafetyBUS p.
If the field devices are in an IP67 environment, suitable cable and connection
materials must be used. The information in the guideline: “SafetyBUS p - IP67
Physical Layer Concept”, published by the SafetyBUS p Club International e.V.,
is binding.
Precise details on the PSS SB ACTIVE JUNCTION BASIS are provided in the
“Technical details” section. Use of the device outside the specifications given
here will be deemed as improper use. Any component, technical or electrical
modifications will be deemed as improper use.
Use of the PSS SB ACTIVE JUNCTION BASIS outside the areas described in
this manual will be deemed as improper use. Intended use includes following the
information in this documentation.
NOTICE
SafetyBUS p subscribers in the following table only support the PSS SB ACTIVE
JUNCTION BASIS from the stated version number onwards:
Table 1
From version
3.0
2.0
2.0
2.0
1.7
2.0
2.0
SafetyBus p module
PSS SB CPU
PSS SB 3006 CN-A
PSS SB 3006 DP-S
PSS SB 3006 IBS-S
PSS SB DI8O8
PSS SB DI16
PSS SB Router1
