Pilz PSWZ X1P User Manual

Safe monitoring relays
Pilz GmbH & Co. KG, Felix-Wankel-Straße 2, 73760 Ostfildern, Germany
Telephone: +49 711 3409-0, Telefax: +49 711 3409-133, E-Mail: pilz.gmbh@pilz.de
Up to PL e of EN ISO 13849-1
PSWZ X1P
NSG-D-2-336-2009-11
Technische Daten_S atz Normen
The standards current on 2008-07 apply.
Bestel ldaten
Storage temperature -40 - 85 °C
Protection type
Mounting (e.g. cabinet) IP54
Housing IP40
Terminals IP20
Mechanical data
Housing material
Housing PPO UL 94 V0
Front ABS UL 94 V0
Cross section of external conductors with screw terminals
1 core flexible 0.25 - 2.50 mm² , 24 - 14 AWG Order no.: 777949, 777950,
777951, 777959
2 core, same cross section, flexible:
with crimp connectors, without insulating sleeve 0.25 - 1.00 mm² , 24 - 16 AWG Order no.: 777949, 777950,
777951, 777959
without crimp connectors or with TWIN crimp connectors 0.50 - 1.50 mm² , 24 - 16 AWG Order no.: 777949, 777950,
777951, 777959
Torque setting with screw terminals 0.60 Nm Order no.: 777949, 777950, 777951, 777959
Cross section of external conductors with spring-loaded termi-
nals: Flexible with/without crimp connectors
0.20 - 1.50 mm² , 24 - 16 AWG Order no.: 787949, 787950,
787951
Spring-loaded terminals: Terminal points per connection 2 Order no.: 787949, 787950, 787951
Stripping length 8 mm Order no.: 787949, 787950, 787951
Dimensions
Height 101.0 mm Order no.: 787949, 787950, 787951
94.0 mm Order no.: 777949, 777950, 777951, 777959
Width 45.0 mm
Depth 121.0 mm
Weight 315 g Order no.: 787949, 787950, 787951
320 g Order no.: 777949, 777950, 777951, 777959
Environmental data
Order reference
Type Features Terminals Order no.
PSWZ X1P C 24 - 240 VAC/DC 0.02 - 0.5 V Spring-loaded terminals 787 949
PSWZ X1P 24 - 240 VAC/DC 0.02 - 0.5 V Screw terminals 777 949
PSWZ X1P C 24 - 240 VAC/DC 0.12 - 3 V Spring-loaded terminals 787 950
PSWZ X1P 24 - 240 VAC/DC 0.12 - 3 V Screw terminals 777 950
PSWZ X1P C 24 - 240 VAC/DC 0.0075 – 0.5 V Spring-loaded terminals 787 951
PSWZ X1P 24 - 240 VAC/DC 0.0075 – 0.5 V Screw terminals 777 951
PSWZ X1P
(coated version)
24 - 240 VAC/DC 0.02 - 0.5 V Screw terminals 777 959
