Pilz PSWZ X1P User Manual

Safe monitoring relays
Up to PL e of EN ISO 13849-1
PSWZ X1P
NSG-D-2-336-2009-11Pilz GmbH & Co. KG, Felix-Wankel-Straße 2, 73760 Ostfildern, Germany
Telephone: +49 711 3409-0, Telefax: +49 711 3409-133, E-Mail: pilz.gmbh@pilz.de
-4
Terminal configuration
Klemmenbelegung
Installation
Montage_PNOZ_X
` The safety relay should be installed
in a control cabinet with a protec-
tion type of at least IP54.
` Use the notch on the rear of the unit
to attach it to a DIN rail.
` Ensure the unit is mounted securely
on a vertical DIN rail (35 mm) by us-
ing a fixing element (e.g. retaining
bracket or an end angle).
Dimensions
Abmessungen
* with spring-loaded terminals
45
(1.77")
121 (4.76")
* 101 (3.98")
94 (3.70")

Pilz PSWZ X1P Specifications

General

Brand	Pilz
Model	PSWZ X1P
Category	Relays
Language	English
