Pima Captain 8 Installation Guide

Hunter-Pro Series
9
No.
Terminal
Description/Connected accessories
1
ZONES Z1-Z8
8 dry contact detector inputs. Loops can have one or two EOL (End
Of Line) resistor supervision.
2
(+V)/(-)/AGND
 “+”: 12VDC power supply for detectors
 “-”/AGND: Common
3
KEY
Input for momentary or ON/OFF key switches and remote controls.
4
SIRENS Ext., Int.
Terminals for connecting external and internal Sirens/horns. The
terminals are protected by automatic thermal fuses F2, F3. See more
details in section 10.5, on page 67.
5
RELAY
Output for triggering gates, spotlights, etc.
6
Smoke
Fire, Smoke & Anti-Mask detectors’ reset output. To manually reset a
detector, press [*] for 2 seconds.
7
KEYPAD
Input/output and power supply for keypads & expanders (BUS). The
terminals are:
 '+'/'-': 13.8 VDC F4 thermal fuse protects the terminals
 IN/OUT: Data
8
ALRM
Transistor output. By default, the output is switched to (-) when an
alarm is set off.
9
ON/OFF
Transistor output. By default, the output is switched to (-) when the
system is armed.
10
TMPR1/2
Tamper switched inputs. TMPR 2 input can instead serve as an input
for additional zone (#9) see page 24.
11
EGND
Earth ground terminal, is to be used in places with severe electrical
activity (abnormal levels of lightning or electrical discharge). Connect
the terminal to metal cold water pipe or AC power outlet ground.
PIMA’s transformer does not require earth ground.
12
LINE
Phone line input terminals.
13
SET
Answering machine, fax and telephone sets terminals.
14
AUDIO IN, OUT,
CONT
Input/output for the MIC-200 microphone, VU-20U voice module,
GSM-200 cellular communicator & the SMS-100 module.
15
SERIAL
Input for the net4pro network module, FSK radio transmitters and
“Smart Home” systems.
16
Expansion Cards
Connector for the OUT-1000 & EXP-PRO UNIV local expanders.
17
KEYPAD
Connector for Technician keypad
18
TRANSMITTER
Connector for the GSM-200 cellular communicator, the TRV/TRU-100
radio transmitters and the SMS-100 module.
 The GSM-200 and the SMS-100 modules cannot
be installed together!
 To connect a radio transmitter together with
the GSM-200, you must use a special cable
(P/N 3411058).
