Pioneer DJM-S9 User Manual

Block Diagram
Peak
Limiter
CH 1/2 Cue
Headphone Mix
Headphone Level
USB Output Level
Master Cue
FX Send
Headphone Out
FILTER
(NOISE)
CH 1/2
3Band
ISOLATOR
CH 1/2
3Band
ISOLATOR
CHx
BEAT FX
PreFILTER
CH 1/2
BEAT FX
PreFader
CH 1/2
Level Meter CH 1/2
CH 1
CH 2
BPM CH 1/2 Detect
CUE
Monitor
CH 1/2
Analog PHONO
Analog CD/LINE
CH Fader
CH 1/2 Control Tone
MIC in
Post CH 1/2 Fader
TalkOver ON/OFF
MIX (Rec Out)
Master Cue
MIC
MIC
Cross Fader B
Cross Fader A
FX Send
AUX
Level meter Master
CH 1/2 Common
Digital Trim
CH 1/2 Cue
Cross Fader
Talk Over
Master
Cue
Talk Over
Level
Talk Over
Mode
Advanced
/Normal
BEAT FX
PostFader
CH 1/2
Master
Level
Booth Level
Booth ATT.
MIC to
Booth Monitor On/Off
Booth Out
Master Out
TalkOver ON/OFF
USB A in
USB B in
MIC
Peak
Limiter
CH1/2 Control Tone
Post CH1/2 Fader
Cross Fader A
Cross Fader B
MIC
AUX
MIX(REC OUT)
USB A SAMPLER
USB B SAMPLER
USB A out
USB B out
USB A out
USB B out
FILTER
(PITCH)
CH 1/2
CH 1/2 Fader Curve
CH 1/2 Fader Reverse
TalkOver ON/OFF
Cross Fader Curve
Cross Fader CutLag
FILTER
(DUB ECHO)
CH 1
FILTER
(DUB ECHO)
CH 2
Cross Fader Reverse
MIC On/Off
Headphone
Cue Fader
AUX in
FX Return
Booth
Mono/
Stereo
Master
Mono/
Stereo
AUX Level
BEAT FX
SAMPLER
BEAT FX
AUX
Output
Select
2Band
MIC EQ
MIC
Filter
MIC In
Level Detect
MIC
ECHO
About trademarks and registered
trademarks
! "Pioneer DJ" is a trademark of PIONEER CORPORATION, and is used
under license.
The names of companies and products mentioned herein are trade-
marks or registered trademarks of their respective owners.
Cautions on copyrights
Recordings you have made are for your personal enjoyment and accord-
ing to copyright laws may not be used without the consent of the copy-
right holder.
! Music recorded from CDs, etc., is protected by the copyright laws of
individual countries and by international treaties. It is the full respon-
sibility of the person who has recorded the music to ensure that it is
used legally.
! When handling music downloaded from the Internet, etc., it is the
full responsibility of the person who has downloaded the music to
ensure that it is used in accordance with the contract concluded
with the download site.
© 2015 Pioneer DJ Corporation. All rights reserved.
<DRI1310-A>
En
36

Pioneer DJM-S9 Specifications

General

Microphone in	Yes
USB connector type	USB Type-B
USB ports quantity	2
Microphone connectivity	XLR
Apple docking compatibility	Not supported
Number of microphone inputs	1
MIDI	24 bit
Sample rate	48 kHz
Product color	Black
Frequency range	20 - 20000 Hz
Number of controls	5
Built-in optical drive	No
Number of mixer channels	2 channels
Signal-to-Noise Ratio (SNR)	107 dB
Number of dedicated effects controls	15
Total Harmonic Distortion plus Noise (THD+N)	0.005 %
Input voltage	100 - 240 V
Power supply type	AC
Minimum RAM	4 GB
Minimum processor	Core i3, i5 or i7
Minimum processor speed	1.07 GHz
Mac operating systems supported	Mac OS X 10.10 Yosemite, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
Windows operating systems supported	Windows 7 Ultimate, Windows 8.1
Minimum display resolution requirement	1280 x 720 pixels

Weight and Dimensions

Depth	407.3 mm
Width	267 mm
Height	107.9 mm
Weight	4600 g
