Pioneer MEP-7000 User Manual

SPECIFICATIONS
9
En
English
SPECIFICATIONS
1 General
Model . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . MEP-7000
Name . . . . . . . . . . . . . . . . . . . . . . . . . . . Multi entertain
ment player
Normal style
Power voltage . . . . . .
. . . . . . . . . . . . . . . . . . . . . .AC 120 V, 60Hz
Power consumption
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33 W
Manipulator style
Power voltage . . . . . .
. . . . . . . . . . . . . . DC 5 V (USB bus-power)
Current consumption
. . . . . . . . . . . . . . . . . . . . . . . . . . . . 600 mA
Power consumption
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 W
Operating temperature .
. . . . . +5 °C to +35 °C (+41 °F to +95 °F)
Operating humidity . . . . .
5 % to 85 % RH (without condensation)
Mass (Weight)
Control unit . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . 1.7 kg (3.75 lb)
Drive unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6.1 kg (13.45 lb)
Max
imum external dime
nsions
Control unit . . . . .
482.6 mm (W) x 133.0 mm (H) x 83.5 mm (D)
19.0 in (W) x 5.24 in (H) x
3.29 in (D)
Drive unit . . . . . . . 482.6 mm (W) x 90.5 mm (H) x 324.6 mm (D)
19.0 i
n (W) x 3.56 in (H) x 12.78ap in (D)
2 USB Upstream Section
Connector. . . . . . . . . . . . . . . . . . . .USB B-type port (PC connector)
USB Downstream Section
Connector. . . . . . . . . . . . . . . USB A-type ports (USB1/USB2 ports)
Power supply . . . . . . . . .
. . . . . . . . . . . .5 V/500 mA or less (at port)
3 Analog Audio Output Section
Output connector . . . . . . . . . . . . . . . . . RCA jacks (controller A/B)
Output level . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . 2.0 Vrms (1 kHz)
Frequency response . . .
. . . . . . . . . . . . . . . . . . . . . . .4 Hz to 20 kHz
S/N ratio . . . . . . . . . . . . . . . . . . . . . . . . . . . . 115 dB or more (J
EITA)
Distortion . . . . . . . . . . . . . . . . . . . . . . . . . . . 0.006 % or le
ss (JEITA)
* The above specifications refer to values for music CD (CD-
DA).
4 Digital Audio Output Section
Output connector . . . . . . . . . . . . . . . . . RCA jacks (controller A/B)
Output type. . . . . . . . . . . . . . . . . . . . . . . . . .
Coaxial digital (S/PDIF)
Output level . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . 0.5 Vp-p (75 Ω)
Output form
at . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44.1 kHz/16 bit
5 Video Output Section
Output connector . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .RCA jack
Composite output level .
. . . . . . . . . . . . . . . . . . . . . . . .1 Vp-p (75 Ω)
6 Center Display Section
Type. . . . . . . . . . . . . . . . . . . . . . . . . . . TFT LCD active matrix display
Size . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4.3” (WIDE)
Supported language
s
. . . . . 10 languages including English, Japanese, and Chinese
7 Controller Display A/B Section
Type. . . . . . . . . . . . . . . . . . . . . . . . . OEL (Organic EL) Full segment
8 Other Connectors
Control unit
Remote control connector . . . . . . . . . . . . . . . . . M
ini-DIN 10-pin
5 V connector. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
DC jack
Drive unit
Remote control connector . . . . . . . . . . . . . . . . . M
ini-DIN 10-pin
Control jack . . . . . . . . . . . . . . . . . . . . Mini-jacks (controller A/B)
Specifications and appearance are subject to change without
notice.
MEP-7000_KU_EN.book 9 ページ ２００９年２月１２日 木曜日 午後３時１５分

Pioneer MEP-7000 Specifications

General

Frequency range	4 - 20000 Hz
Channels quantity	- channels
Digital sound processing	- bit
Total Harmonic Distortion (THD)	0.006 %
Dimensions (WxDxH)	483 x 325 x 91 mm
Power consumption (typical)	33 W

Weight and Dimensions

Weight	6100 g
