PD-F958, PD-F908
7
(2) CONTRAST TABLE
PD-F908/KUXQ,KCXQ and PD-F958/KUXQ/CA have the same construction except for the following:
Mark No. Symbol & Description Remarks
Part No.
PD-F958/ PD-F908/ PD-F908/
KUXQ/CA KUXQ KCXQ
1 Main Board Assy PWZ3895 PWZ3876 PWZ3876
2 Power Board Assy PWZ3900 PWZ3879 PWZ3879
3 Display Board Assy PWZ3904 PWZ3882 PWZ3882
NSP 4 Switch Board Assy PWZ3907 PWZ3885 PWZ3885
NSP 5 Door Board Assy PWZ3913 PWZ3890 PWZ3890
NSP 6 Center LED Board Assy PWZ3915 PWZ3892 PWZ3892
11 F.F.C/30V PDD1186 PDD1167 PDD1167
(40P F.F.C) (32P F.F.C) (32P F.F.C)
13 Rubber Sheet Not Used AEB1111 AEB1111
18 Rear Base PNA2452 PNA2450 PNA2450
20 Insulator PNW2766 Not Used Not Used
44 Function Button PAC1908 PAC1905 PAC1905
47 Display Window PAM1772 PAM1774 PAM1774
50 Operation panel PNW2869 PNW2867 PNW2867
55 65 Label ORW1069 ORW1069 Not used
To Next Page
