Pioneer PD-F908 User Manual

PD-F958, PD-F908
9
Mark No. Description Part No.
1
…………
2
…………
NSP 3 Loading Motor Board Assy PWZ3337
NSP 4 Load SW Board Assy PWZ3334
5 Arm A Spring2 ABH7124
6 Gear Plate Spring ABH7051
7 Clamp Spring ABH7107
8
…………
9
…………
10 Loading Belt AEB7029
11
…………
12
…………
13
…………
NSP 14 Servo Stopper S ANB7047
15 Loading Base ANW7086
16 Cam Cover ANW7052
17 Motor Holder ANW7053
18 Sensor Holder ANW7119
19 Float Base 96 PNW2700
20 Clamper Holder ANW7117
21 Arm A2 ANW7128
22 Arm (B) ANW7058
23 Drive Plate ANW7059
24 Arm Plate ANW7060
25 Gear Plate ANW7111
26 Gear Pulley (B) ANW7062
27 Gear A ANW7063
28 Drive Gear ANW7064
29
…………
30
…………
31
…………
32
…………
33
…………
34 Roller B ANW7075
35 Motor Pulley PNW1634
36 Clamper PNW2743
37 Float Spring ABH7049
38 Connector Assy (4P) RDE1043
39 Float Rubber AEB7028
NSP 40 Servo Mechanism Assy GM PXA1591
41 Screw IPZ20P080FMC
42
…………
43
…………
44 Motor Assy AEA7006
45 Loading Motor VXM1034
46 16P FFC/30V PDD1180
Froil (for Service) GYA1001
Ha Narl (for Service) GEM1016
LOADING MECHANISM ASSY PARTS LIST

Pioneer PD-F908 Specifications

General

Brand	Pioneer
Model	PD-F908
Category	CD Player
Language	English
