(1) PACKING SECTION PARTS LIST
(2) CONTRAST TABLE
PDP-427XD/WYVIXK5, PDP-4270XD/WYVIXK5, PDP-4270XA/WYVIXK5, WYV5, PDP-427XA/WYVIXK5 and
WYV5 are constructed the same except for the following:
Mark
No. Description Part No.
> 1Power Cord (2 m) ADG1214
2Power Cord Lid See Contrast table (2)
3 Remote Control Unit See Contrast table (2)
4 Battery Cover See Contrast table (2)
5 Operating Instructions See Contrast table (2)
(Italian,Dutch,Spanish)
6 Operating Instructions See Contrast table (2)
(English,French,German)
7 Block Diagram See Contrast table (2)
NSP 8 Dry Cell Battery (R06, AA) VEM1031
> 9Ferrite Core (L5321) ATX1039
10 Binder Assy AEC1908
NSP 11 Hexagonal Wrench (6 mm) See Contrast table (2)
12 Cleaning Cloth AED1285
13 Caution Card See Contrast table (2)
14 Cleaning Caution See Contrast table (2)
NSP 15 Warranty Card ARY1114
16 Polyethylene Bag AHG1340
17 Polyethylene Bag AHG1326
18 Polyethylene Bag AHG1337
19 Pad (427 T-L) See Contrast table (2)
20 Pad (427 T-R) See Contrast table (2)
21 Pad (427 B-L) See Contrast table (2)
22 Pad (427 B-R) See Contrast table (2)
23 Under Carton (427) See Contrast table (2)
24 Upper Carton See Contrast table (2)
25 Mirror Mat See Contrast table (2)
Mark
No. Description Part No.
Mark No. Symbol and Description
PDP-427XD
/WYVIXK5
PDP-4270XD
/WYVIXK5
PDP-4270XA
/WYVIXK5
PDP-427XA
/WYVIXK5
PDP-4270XA
/WYV5
PDP-427XA
/WYV5
2Power Cord Lid AHC1087 AHC1087 AHC1087 AHC1087 AHC1085 AHC1085
3 Remote Control Unit AXD1532
AXD1515
AXD1541 AXD1540 AXD1541 AXD1540
4 Battery Cover AZA7626 AZA7424 AZA7424 AZN2626 AZA7424 AZN2626
5 Operating Instructions
(Italian,Dutch,Spanish)
ARC1562 ARC1565 Not used ARC1564 Not used ARC1563
6 Operating Instructions
(English,French,German)
ARE1428 ARE1431 ARE1433 ARE1430 ARE1432 ARE1429
7 Block Diagram ARY1189 ARY1189 ARY1189 ARY1189 Not used Not used
NSP 11 Hexagonal Wrench (6 mm) Not used
AEF1029
AEF1029 Not used AEF1029 Not used
13 Caution Card ARM1310 ARM1310 ARM1310 ARM1310 ARM1232 ARM1232
14 Cleaning Caution PTK ARM1311 ARM1311 ARM1311 ARM1311 Not used Not used
14 Wiping Cloth Caution Not used Not used Not used Not used ARM1283 ARM1283
19 Pad (427 T-L) AHA2554 AHA2554 AHA2554 AHA2554 AHA2534 AHA2534
20 Pad (427 T-R) AHA2555 AHA2555 AHA2555 AHA2555 AHA2535 AHA2535
21 Pad (427 B-L) AHA2600 AHA2600 AHA2600 AHA2600 AHA2592 AHA2592
22 Pad (427 B-R) AHA2601 AHA2601 AHA2601 AHA2601 AHA2593 AHA2593
23 Under Carton (427) AHD3496 AHD3496 AHD3496 AHD3496 AHD3471 AHD3471
24 Upper Carton AHD3515 AHD3514 AHD3497 AHD3517 AHD3513 AHD3516
25 Mirror Mat AHG1327 AHG1327 AHG1327 AHG1327 AHG1284 AHG1284

Pioneer PDP-427XD Specifications

General

Depth	115 mm
Width	1040 mm
Height	679 mm
Weight	29600 g
Pixel pitch	- mm
Aspect ratio	16:9
Product color	Black
LED indicators	Stand-by
Noise reduction	Yes
RMS rated power	13 W
Display diagonal	42 \
Headphone outputs	1
Display brightness	1100 cd/m²
Display resolution	1024 x 768 pixels
Display technology	Plasma
Power requirements	AC 220 - 240 V, 50/60 Hz
SCART ports quantity	3
Contrast ratio (typical)	3000:1
Analog signal format system	PAL, SECAM
Power consumption (standby)	0.7 W
Power consumption (typical)	291 W
