9.3 OUTLINE OF EACH COMMANDS
9.3.1 ACQUISITION OF PANEL STATUS • • • [QS1]
Model information and version information are returned.
Command
Format
Effective Operation
Modes
Function Remarks
[QS1] Every Time Output of status Return data: 105 Byte
1: Resolution/Inch size
3 1024∗768/42
4 1024∗768/43
5 1280∗768/50
6 1365∗768/50
7 1365∗768/60
F 1920∗1080/50
2: Panel Generation
6G6
7G7
8G8
9G9
0 G10
3: Destination
∗ Commonness
A US (Reserved)
E EU (Reserved)
J Japan (Reserved)
12: Panel Type
P
The past
F
High-effiective
4: System Type
∗ Commonness
Z Evaluation
Data Arrangement
Data
Length
Output Example
ECO 3 byte QS1 (Fixed)
1 Display information 1 (Resolution/inch size) 1 byte F
2 Display information 2 (Panel Generation) 1 byte 7: G7
3 Display information 3 (Destination) 1 byte A: USA
4 Display information 4 (System Type) 1 byte ∗
5 Display information 5 (Panel Product Form) 1 byte B
6 MDUcom-Boot 3 byte 01A
7 MDUcom-Prg 8 byte
8 Seq Prs-Boot 3 byte 01A
9 Seq Prs-Prg 8 byte
10 SQ-VIDEO 4 byte
11 SQ-PC 4 byte
12 Panel Type 1 byte P/F
13 Reserved (∗)7 byte ∗∗∗∗∗∗∗
14 , (comma) 1 byte
15 MTB information 1 (Generation) 1 byte 7: G7
16 MTB information 2 (Regional model) 1 byte A: USA
17 MTB information 3 (Grade) 1 byte H: Elite
18 MTB information 4 (System Type) 1 byte B
19 Common version for IF microcomputer 4 byte
20 Common version for Main microcomputer 8 byte
21 Boot version of Main microcomputer 4 byte
22 Common version for Multi-processor 8 byte
23 Boot version of Multi-processor 4 byte
24 Reserved (∗)
Check Sum
24 byte
25 2 byte FF
5: Panel Product Form
S System model
B All-in-one design TV
M Monitor
D Standard module
E Simple module
15: MTB/MB Generation
6
G6
7
G7
8
G8
9
G9
0
G10
16: Regional Model
JJP
AUS
EEU
GGE
CCH
UAU
17: MTB/MB Grade
H Elite/DXA/Step-upD
T Step-upA/XG/TXC/Regular (US)
B Not used (For Future)
18: MTB/MB Product Form
S System model
B One body model (SX)
M Monitor (FHD)
S RegularD
R RegularA
19 to 23: MTB/MB-side's information
IF uCON Common version of IF microcomputer
Main uCON Common version of Main microcomputer
Main uCON-Boot
Boot version of Main microcomputer
Multi-prs Common version of Multi-processor
program
Multi Prs-Boot Boot version of Multi-processor program

Pioneer PDP-427XD Specifications

General

Depth	115 mm
Width	1040 mm
Height	679 mm
Weight	29600 g
Pixel pitch	- mm
Aspect ratio	16:9
Product color	Black
LED indicators	Stand-by
Noise reduction	Yes
RMS rated power	13 W
Display diagonal	42 \
Headphone outputs	1
Display brightness	1100 cd/m²
Display resolution	1024 x 768 pixels
Display technology	Plasma
Power requirements	AC 220 - 240 V, 50/60 Hz
SCART ports quantity	3
Contrast ratio (typical)	3000:1
Analog signal format system	PAL, SECAM
Power consumption (standby)	0.7 W
Power consumption (typical)	291 W
