Pioneer PDP-433MXE Service Manual

30
PDP-433CMX
2.17 PANEL CHASSIS (43) ASSY (AWU1067)
NSP SCAN FUKUGO ASSY AWV1969
NSP SCAN (A) ASSY AWZ6724
NSP SCAN (B) ASSY AWZ6725
NSP X CONNECTOR (A) ASSY AWZ6726
NSP X CONNECTOR (B) ASSY AWZ6727
NSP BRIDGE A ASSY AWZ6728
NSP BRIDGE B ASSY AWZ6729
NSP BRIDGE C ASSY AWZ6730
NSP BRIDGE D ASSY AWZ6731
ADDRESS FUKUGO ASSY AWV1928
NSP ADR CONNECT A ASSY AWZ6678
NSP ADR CONNECT B ASSY AWZ6679
NSP ADR CONNECT C ASSY AWZ6680
NSP ADR CONNECT D ASSY AWZ6681
ADR RESONANCE ASSY AWZ6751
Mark No. Description Part No.
•
LIST OF ASSY
Panel Chassis (43) Assy (AWU1067) consists of the following parts.
NSP SCAN FUKUGO ASSY AWV1969
NSP ADDRESS FUKUGO ASSY AWV1928
NSP Address Module (IC1 - IC32) AXF1113
NSP FPC (J1,J2) ADY1079
NSP FPC (J3,J4) ADY1080
NSP Chassis Assy (43) ANA1693
NSP Chassis (43) ANA1668
NSP Base Chassis (43) ANA1669
NSP Scan Heatsink (43) ANH1601
NSP Corner Angle A ANG2457
NSP Corner Angle B ANG2458
NSP Tube Cover AMR3262
Silicone Sheet 43 AEH1043
Adhesive Tape 43 AEH1044
Adhesive Tape B 43 AEH1054
Panel Silicone Sheet AEH1055
Silicone Sheet B 43 AEH1056
Pin Grommet AEC1015
Card Spacer AEC1889
Scan Silicone Sheet (43) AEH1047
NSP Plasma Panel Assy (43) AAV1239
Screw VBB30P100FNI
•
PARTS LIST
Mark No. Description Part No.
2.16 PDP SERVICE ASSY 433 (AWU1069)
•
PARTS LIST
Mark No. Description Part No. Mark No. Description Part No.
Panel Chassis (43) Assy AWU1067
NSP Front Chassis V (43) ANA1702
NSP Front CHassis HU (43) ANA1698
NSP Front Chassis HL ANA1700
NSP Sub Frame L (43) ANG2517
NSP Sub Frame R (43) ANG2518
Scan IC Spring (43L) ABK1029
Scan IC Spring (43R) ABK1030
NSP Metal Fitting ANG2464
FPC Cushion (43) AEB1371
NSP PCB Spacer AEC1121
Locking Card Spacer AEC1736
Circuit Board Spacer AEC1872
Circuit Board Spacer AEC1873
Spacer AEC1896
NSP Card Spacer AEC1902
Wire Saddle AEC1904
Panel Cushion H (43) AED1200
Panel Cushion V (43) AED1201
V Cushion AED1205
Insullation Sheet AMR3263
Scan Sheet (43) AMR3287
Card Corner Holder BEC1144
Screw ABA1283
Screw ABA1294
Screw ABZ30P060FMC
Screw BMZ30P060FMC
Screw PMB30P060FNI
Screw VBB30P100FNI
Bolt ABA1259
Corner Pad AHA2293
Upper Carton AHD3139
Under Carton AHD3140
Packing Sheet AHG1291
Washer WB80FZB
VR Cushion AEB1374
Niplocker AEC1803
Static Plate AHK1013
Plate AHK1014
Screw BYC40P220FMC
Washer WC60FZK
Serivec Panel notes ARM1217
PDP Service Assy 433 (AWU1069) consists of the following parts.
