Pioneer PDP-433MXE Service Manual

71
PDP-433CMX
5
678
5
6
7
8
C
D
F
A
B
E
Name OSD Display Name RS-232C Command Service Factory Operation
Adjustment Range
[OFFSET Reference Value]
Name OSD Display Name RS-232C Command Service Factory Operation
Adjustment Range
[OFFSET Reference Value]
Name OSD Display Name RS-232C Command Service Factory Operation
Adjustment Range
[OFFSET Reference Value]
Name OSD Display Name RS-232C Command Service Factory Operation
Adjustment Range
[OFFSET Reference Value]
Name OSD Display Name RS-232C Command Service Factory Operation
Adjustment Range
[OFFSET Reference Value]
CD
YDL Y-DELAY YDL REF/OFS-SLOT-1 0 to 15 [8]
YOUTLEV Y-OUT LEVEL YOL REF/OFS-SLOT-2 0 to 63 [32]
TINT CD TINT CTI REF/OFS-SLOT-3 0 to 63 [32]
CrOFFSET CDR OFFSET CDR REF/OFS-SLOT-4 0 to 15 [8]
CbOFFSET CDB OFFSET CDB REF/OFS-SLOT-5 0 to 15 [8]
EXP
R-Y_LEVEL R-Y LEVEL LRY REF/OFS-SLOT-6 0 to 255 [128]
B-Y_LEVEL B-Y LEVEL LBY REF/OFS-SLOT-7 0 to 255 [128]
MATRIX
PICTURE MAT CONT MCT REF/OFS-RGB1-1 0 to 63 [32]
BRIGHT MAT BRIGHT MBR REF/OFS-RGB1-2 0 to 63 [32]
COLOR MAT COLOR MCL REF/OFS-RGB1-3 0 to 63 [32]
HUE MAT TINT MTI REF/OFS-RGB1-4 0 to 63 [32]
AD
MAINCONTRAST AD MAIN CONT MCA REF/OFS-RGB1-5 0 to 255 [128]
SUBRCONTRAST AD R HIGH GHA REF/OFS-RGB1-6 0 to 255 [128]
SUBGCONTRAST AD G HIGH BHA REF/OFS-RGB1-7 0 to 255 [128]
SUBBCONTRAST AD B HIGH RHA REF/OFS-RGB1-8 0 to 255 [128]
BRIGHTR AD R LOW GLA REF/OFS-RGB1-9 0 to 255 [128]
BRIGHTG AD G LOW BLA REF/OFS-RGB1-10 0 to 255 [128]
BRIGHTB AD B LOW RLA REF/OFS-RGB1-11 0 to 255 [128]
IC102
W/B
COLOR COLOR COL REF/OFS-RGB2-1 0 to 255 [128]
TINT TINT TNT REF/OFS-RGB2-2 0 to 255 [128]
IC30
W/B
MCONTRAST CONTRAST CNT REF/OFS-RGB2-3 0 to 255 [128]
MBRIGHT BRIGHT BRT REF/OFS-RGB2-4 0 to 255 [128]
R HIGH R. HIGH RHI REF/OFS-RGB2-5 0 to 255 [255]
G HIGH G. HIGH GHI REF/OFS-RGB2-6 0 to 255 [255]
B HIGH B. HIGH BHI REF/OFS-RGB2-7 0 to 255 [255]
R LOW R. LOW RLW REF/OFS-RGB2-8 0 to 255 [128]
G LOW G. LOW GLW REF/OFS-RGB2-9 0 to 255 [128]
B LOW B. LOW BLW REF/OFS-RGB2-10 0 to 255 [128]
DIGITAL
PANEL R-HIGH PANEL R-HIGH PRH REF/OFS-DIGITAL-1 0 to 255 [255]
PANEL G-HIGH PANEL G-HIGH PGH REF/OFS-DIGITAL-2 0 to 255 [255]
PANEL B-HIGH PANEL B-HIGH PBH REF/OFS-DIGITAL-3 0 to 255 [255]
PANEL R-LOW PANEL R-LOW PRL REF/OFS-DIGITAL-4 0 to 999 [512]
PANEL G-LOW PANEL G-LOW PGL REF/OFS-DIGITAL-5 0 to 999 [512]
PANEL B-LOW PANEL B-LOW PBL REF/OFS-DIGITAL-6 0 to 999 [512]
ABL LEVEL ABL LEVEL ABL REF/OFS-DIGITAL-7 0 to 255 [128]
X-SUS-B X-SUS-B XSB REF-DIGITAL-8 4 to 12
X-SUS-G X-SUS-G XSG REF-DIGITAL-9 4 to 12
Y-SUS-B Y-SUS-B YSB REF-DIGITAL-10 4 to 12
Y-SUS-G Y-SUS-G YSG REF-DIGITAL-11 4 to 12
V-SUS V-SUS VSU REF-DIGITAL-12 0 to 255
V-OFFSET V-OFFSET VOF REF-DIGITAL-13 0 to 255
IC30
R SIDE MASK LEV R SIDE MASK LEV RSL VOP-M LEV-1 0 to 255
G SIDE MASK LEV G SIDE MASK LEV GSL VOP-M LEV-2 0 to 255
B SIDE MASK LEV B SIDE MASK LEV BSL VOP-M LEV-3 0 to 255
SLOT
RGB1
RGB2
DIGITAL
SIDE MASK LEVEL (VIDEO OPTION)
6.1.2 TABLE OF ADJUSTMENT ITEMS IN SERVICE FACTORY
