06Preparation
English
17
En
Shock absorbing pad
3. Remove the shock absorbing pads.
Keep the shock absorbing pads and screws. They are required
when you place the Media Receiver in the horizontal position.
4. Plug the screw holes using the supplied caps.
• When you have installed the Media Receiver vertically,
be sure to use the supplied stand. If you place the unit
directly on the floor, the cooling vents will be blocked,
resulting in mechanical failure.
Remove the separation sheet.
Screw hole cap
Align with the
hole and attach.
To Next Page
