Pioneer PDP-506PU User Manual

PDP-506PE
70
1234
1234
C
D
F
A
B
E
5. PANEL-1 ADJ
<Drive-sequence indications and indications for the ABL/WB tables>
(The OSD indications are displayed at the right part of the third line for submode PANEL-1 ADJ and
subsequent submodes.)
<Lower-layer items of PANEL-1 ADJ>
A.PNEL
L/1
[
BT60VS
]
I–N1 5 2060 –RGB HE–S6FACT
AJPNEL–1AD )(+
1
5
10
15
16
15 10 15 20 25 30 32
<DOWN> : Shifting to the next item
<UP> : Shifting to the previous item
<RIGHT> : Adding by one to the adjustment
value
<LEFT> : Subtracting by one from the
adjustment value
<VOL+> : Adding by 10 to the adjustment
value
<VOL-> : Subtracting by 10 from the
adjustment value
<SET> : Determining the adjustment value
and shifting to the upper layer
<SEL> : MASK ON/OFF
A.PNEL
L/1
[
BT60VS
]
I–N1 5 2060 –RGB HE–S6FACT
–>XSUS–B<=
AJPNEL–1AD
2:1 8
1
5
10
15
16
15 10 15 20 25 30 32
Type of WB/ABL Tables
Type of Drive Sequences
Standard Video/MASK ON Nonstandard Video PC
TBL1 48VS --- 60PS Not used for consumer products
TBL2 50VS 50VN 70PS
TBL3 60VS 60VN
TBL4 72VS Only Mask indication ---
75VS 75VN
No. Items Adjustment/Setting Value Remarks
1 X-SUS B <=> 120 to 136 Equivalent to XSB
2 Y-SUS B <=> 120 to 136 Equivalent to YSB
3 Y-SUSTAIL T <=> 120 to 136 Equivalent to YTG
4 Y-SUSTAIL W <=> 120 to 136 Equivalent to YTW
5 XY-RST W <=> 120 to 136 Equivalent to RSW
6 VOL SUS <=> 000 to 255 Equivalent to VSU
7 VOL OFFSET <=> 000 to 255 Equivalent to VOF
8 VOL RST P <=> 000 to 255 Equivalent to VRP
9 SUS FREQ. <=> <=>MODE1 to MODE8<=> Equivalent to SFR
<DOWN> : Shifting to PANEL-2 ADJ (+)
<UP> : Shifting to POWER DOWN
<SET> : Shifting to the next nested layer
<SEL> : MASK ON/OFF
7 Key operation
7 Key operation
