7. PANEL REVISE
<Lower-layer items of PANEL REVISE>
A.PNEL
L/1
[
BT60VS
]
I–N1 5 2060 –RGB HE–S6FACT
ASPNEL E ERVI )(+
1
5
10
15
16
15 10 15 20 25 30 32
A.PNEL
L/1
[
BT60VS
]
I–N1 5 2060 –RGB HE–S6FACT
––>RL LEVE <=
ASEPNEL ERVI
V:L 0
1
5
10
15
16
15 10 15 20 25 30 32
No. Items Adjustment/Setting Value Remarks
1 R-LEVEL <=> <=>LV-0 to LV-7<=> Equivalent to RRL
2 G-LEVEL <=> <=>LV-0 to LV-7<=> Equivalent to RGL
3 B-LEVEL <=> <=>LV-0 to LV-7<=> Equivalent to RBL
<DOWN> : Shifting to ETC.(+)
<UP> : Shifting to PANEL-2 ADJ (+)
<SEL> : MASK ON/OFF
<SET> : Shifting to the next nested layer
7 Key operation
<DOWN> : Shifting to the next item
<UP> : Shifting to the previous item
<RIGHT> : Adding by one to the adjustment
value
<LEFT> : Subtracting by one from the
adjustment value
<VOL+> : Adding by 10 to the adjustment
value
<VOL-> : Subtracting by 10 from the
adjustment value
<SET> : Determining the setting value
and shifting to the upper layer
<SEL> : MASK ON/OFF
7 Key operation
