Pioneer PDP-LX508G User Manual

Preparation
05
16
En
Preventing the plasma television from
falling over
After installing the stand, be sure to take special care to ensure
that the plasma television will not fall over and is stabilized to both
the wall and rack.
Stabilizing on a table or rack
Stabilize the plasma television as shown in the diagram using the
plastic bands and screws supplied with the optional stand.
Note
• To stabilize the plasma television on a table or rack, use screws
that have a nominal diameter of 4 mm and that are at least 20
mm long.
Using a wall for stabilization
1 Attach falling prevention bolts (hooks) to the plasma
television.
2 Use strong cords to stabilize it appropriately and firmly to
a wall, pillar, or other sturdy element.
Perform this work in the same way on the left and right sides.
Use hooks, cords and fittings that are available on the market.
Recommended hook: Nominal diameter 8 mm, length 12 mm to
18 mm.
M
O
N
ITO
R
OUT
S
U
B
W
OO
FER
Screw
(M4 x 10 mm)
Drill a hole in the middle at the rear of the tabletop
panel before using a wood screw. Perform this work
the same way on the left and right sides.
(PDP-LX608G)
8 mm to 15 mm
20 mm min.
4 mm
Wood screw
(commercially available,
4 mm x 20 mm min.)
Screw
(M4 x 10 mm)
M
O
N
I
T
O
R
O
U
T
S
U
B
W
O
O
F
E
R
Screw
Drill a hole in the
middle at the rear
of the tabletop
panel before using
a wood screw.
Perform this work
the same way on
the left and right
sides.
8 mm to 15 mm
20 mm min.
4 mm
Wood screw
(commercially available,
4 mm x 20 mm min.)
Screw
(M4 x 10 mm)
Screw
Wood screw
(PDP-LX508G)
M
O
N
IT
O
R
O
U
T
S
U
B
W
O
O
F
E
R
Fitting
2. Cord
1. Hook
12 mm to 18 mm
M8
