Pioneer PDP-LX508G - Signal Assignments for 15-Pin D-Sub Connector; And Regions

Additional information
13
65
En
English
Signal assignments for 15-pin D-sub connector
Standard channel allocation selections for countries and regions
* When receiving signals from a cable TV company, select “Cable (US Type)” for “Channel Allocation”. See Setting up TV channels
automatically on page 26.
Pin No. Signal assignment Pin No. Signal assignment
1 R 9 +5 V
2 G 10 GND (ground)
3 B 11 Not connected
4 Not connected 12 SDA
5 Not connected 13 HD
6 GND (ground) 14 VD
7 GND (ground) 15 SCL
8 GND (ground)
Region Standard channel allocation Region Standard channel allocation
Taiwan Air (US Type)* Mexico Air (US Type)*
Hong Kong General Chile Air (US Type)*
Philippines Air (US Type)* Brazil Air (US Type)*
Thailand General Australia General
Malaysia General New Zealand General
Singapore General Egypt General
Indonesia General South Africa General
Saudi Arabia General Colombia Air (US Type)*
Israel General Peru Air (US Type)*
Lebanon General Venezuela Air (US Type)*
United Arab Emirates General
