6.6 OUTLINE OF COMMANDS
QS1: Returning information on the module and the version of the software.
QS6: Returning information of the Flash Device.
QMT: Returning information of MR temperature and FAN speed.
Order Part Data Content Size Remarks
0-Received Command Name on MR 3 byte 'QS1' only
1
MDU
Display Information 1 1 byte
2 Display Information 2 1 byte
3 Display Information 3 1 byte
4 Display Information 4 1 byte
5 Display Information 5 1 byte
6 Boot Version of Module microcomputer. 3 byte
7 Program Version of Module microcomputer. 8 byte
8 Boot Version of ASTRA-MANTA 3 byte
9 Program Version of ASTRA-MANTA 8 byte
10 Sequence Version (43VIDEO) 4 byte
11 Sequence Version (43PC) 4 byte
12 Sequence Version (50VIDEO) 4 byte
13 Sequence Version (50PC) 4 byte
14
MR
, (comma) 1 byte
15 MR Infomation 1 1 byte
16 MR Infomation 2 1 byte
17 MR Infomation 3 1 byte
18 MR Infomation 4 1 byte
19 Version of IF microcomputer 4 byte
20 Version of Main microcomputer 8 byte
21 Boot Version of Main microcomputer 4 byte
22 Program Version of CARRERA-MANTA 8 byte
23 Boot Version of CARRERA-MANTA 4 byte
24 GUI Version of CARRERA-MANTA 8 byte
25 Enhanced Version of CARRERA-MANTA 8 byte
26 PIC Version of CARRERA-MANTA 8 byte
Order Data Content Size Remarks
0 Received Command Name on MR 3 byte 'QS6' only
1 Version of DTB (PDP-R06XE only) 4 byte
2 Version of PC Card (PDP-R06XE only) 8 byte
3 Version of Text 60 byte
4 User Passward 4 byte
Order Data Content Size Remark
1 Received Command Name on MR 3 byte 'QMT' only
2 MR Temperature 3 byte
3 MR FAN Speed 1 byte
0: STOP
1: MIN
2: MAX
