Pioneer sc-lx86 - [G] 5.2 channel surround system & ZONE 2;ZONE 3 connection (Multi Zone)

27
03
Connecting your equipment
[G] 5.2 channel surround system & ZONE 2/ZONE 3 connection (Multi Zone)
! Select ‘5.1ch + ZONE 2+3’ from the Speaker System menu.
See Speaker system setting on page 97 to do this.
SUBWOOFER
12
SURROUND SURR BACK F HEIGHT
(Single)
(Single)
FRONT
CENTER
PRE OUT
F WIDE
SPEAKERS
FRONT CENTER
A A
SURROUND
SURROUND BACK
FRONT HEIGHT
FRONT WIDE /
B
RL
RLRLRLRL
LINE LEVEL
INPUT
LINE LEVEL
INPUT
ZONE 3 - leftZONE 3 - right
Front leftFront right
Center Subwoofer 2Subwoofer 1
Surround left
ZONE 2 - right ZONE 2 - left
Surround right
[H] 5.2 channel surround system & Speaker B Bi-amping connection
! Select ‘5.1ch + SP-B Bi-Amp’ from the Speaker System menu.
See Speaker system setting on page 97 to do this.
SUBWOOFER
12
SURROUND SURR BACK F HEIGHT
(Single)
(Single)
FRONT
CENTER
PRE OUT
F WIDE
SPEAKERS
FRONT CENTER
A A
SURROUND SURROUND BACK FRONT HEIGHT FRONT WIDE /
B
RL
RLRLRLRL
LINE LEVEL
INPUT
LINE LEVEL
INPUT
High
Low
High
Low
Front leftFront right
Center Subwoofer 2Subwoofer 1
Surround leftSurround right
Bi-amp compatible
speaker
Speaker B right
Bi-amp compatible
speaker
Speaker B left
