(1) MAIN CHASSIS SECTION (1/2) PARTS LIST
(2) CONTRAST TABLE
SC-LX90/WYPWXJ5, SC-LX90/WVLXJ5 and SC-LX90/LFXJ are constructed the same except for the following:
Mark No. Description Part No.
1 DIGI BRIDGE Assy AWX8752
2 PERCH FFC Assy AWX8782
3 PERCH PS Assy AWX8785
4 ICE REG Assy AWX8751
5 ICE 5 Assy AWX8968
6 ICE 12 Assy AWX8969
7 DD DSP Assy AWX8748
8 DSP DIODE Assy AWX8956
9 HN DIODE Assy AWX8958
10 FAN-12V Assy AWX8959
11 DD DISP Assy AWX8784
12 DD HDMI Assy AWX8750
13 HDMI DIODE Assy AWX8957
14 2CH DD Assy AWX8961
15 PRIMARY Assy See Contrast table (2)
> 16 Power Transformer (T1501) See Contrast table (2)
> 17 Power Transformer (T1502) See Contrast table (2)
> 18 Fuse (FU4501: T1.25A) AEK7074
> 19 Fuse (FU4: T1A) See Contrast table (2)
Fuse (FU4: T1.25A) See Contrast table (2)
> 20 Fuse (FU11,12,4351: T1.6A) AEK7075
> 21 Fuse (FU4301: T3.15A) AEK1059
> 22 Fuse (FU3: T2A) See Contrast table (2)
> Fuse (FU3: T4A) See Contrast table (2)
> 23 Fuse (FU4601: T5A) AEK1061
24 14P FFC (J1931) ADD7592
25 12P FFC (J1932) ADD7593
NSP 26 Panel Stay AND7083
NSP 27 DCDC Angle ANG7560
NSP 28 Trans Frame ANG7561
NSP 29 HS Angle DC ANG7577
NSP 30 Heatsink DC ANH7191
31 Lock Edge Saddle 17L AEC7585
32 Lock Edge Saddle 25L AEC7587
33 Wire Saddle AEC7586
34 PC Support DEC2736
35 Card Spacer AEC7214
36 Wire Saddle DEC1450
37 PCB Spacer AEC7080
NSP 38 PC Support VEC1749
39 Locking Card Spacer PNW2917
40 Duct Cushion AED7115
41 Screw BBZ30P060FCC
42 Screw BBZ30P080FTB
43 Screw BBT30P060FTB
44 Screw 4 x 12 ABA7109
45 Screw BBT30P080FCC
46 Screw CBZ30P080FTB
47 Screw 3 x 9 ABA7101
48 Washer WH40FNI
49 Insulation Sheet A AEC7606
50 Insulation Sheet B AEC7607
51 Insulation Sheet C AEC7608
52 Shield Sheet C AMR7542
NSP 53 Fuse Card AAX2348
NSP 54 Fuse Card See Contrast table (2)
NSP 55 Fuse Card AAX2377
NSP 56 Fuse Card AAX7098
NSP 57 Fuse Card See Contrast table (2)
NSP 58 Fuse Card AAX7493
59 Ferrite Core (L1953) ATX7012
60 Fan Motor (60x15) See Contrast table (2)
NSP 61 Binder (BK-1) ZCA-BK1
62 Harness Lifter AEC7583
63 Screw See Contrast table (2)
Mark
No. Description Part No.
Mark No. Symbol and Description
SC-LX90/
WYPWXJ5
SC-LX90/
WVLXJ5
SC-LX90/
LFXJ
15 PRIMARY Assy AWX8758 AWX8759 AWX8760
> 16 Power Transformer (T1501) ATS7412 ATS7412 ATS7411
> 17 Power Transformer (T1502) ATS7415 ATS7415 ATS7414
> 19 Fuse (FU4: T1A) AEK7073 AEK7073 Not used
Fuse (FU4: T1.25A) Not used
Not used
AEK7074
> 22 Fuse (FU3: T2A) AEK1057 AEK1057 Not used
> Fuse (FU3: T4A) Not used Not used AEK1060
NSP 54 Fuse Card AAX7293 AAX7293 AAX2348
NSP 57 Fuse Card AAX2357 AAX2357 AAX7099
60 Fan Motor (60x15) Not used AXM7034 Not used
63 Screw Not used BBZ30P180FCC Not used
