270
SC-09TX
1
2 3 4
A
B
C
D
E
F
1
2 3 4
12. PCB PARTS LIST
Parts marked by "NSP" are generally unavailable because they are not in our Master Spare Parts List.
The mark found on some component parts indicates the importance of the safety factor of the part.
Therefore, when replacing, be sure to use parts of identical designation.
When ordering resistors, first convert resistance values into code form as shown in the following examples.
Ex.1 When there are 2 effective digits (any digit apart from 0), such as 560 ohm and 47k ohm (tolerance is shown by J=5%,
and K=10%).
Ex.2 When there are 3 effective digits (such as in high precision metal film resistors).
561
473
R50
1R0
5621
NOTES:
560
Ω
47k
Ω
0.5
Ω
1
Ω
RD1/4PU J
RD1/4PU J
RN2H K
RS1P K
56 x 10
1
47 x 10
3
R50
1R0
561
473
5.62k Ω RN1/4PC F562 x 10
1
5621
Meaning of the figures and others in the parentheses in the parts list.
Example) IC 301 is on the point (face A, 91 of x-axis, and 111 of y-axis) of the corresponding
PC board.
IC 301 (A, 91, 111) IC NJM2068V
Mark No. Description Part No.
LIST OF ASSEMBLIES
1..MAIN DIGITAL ASSY AWK7949
2..MAIN DIGITAL ASSY AWX8721
2..DAC ASSY AWX8723
1..VIDEO COMPLEX ASSY AWK7951
2..S-VIDEO ASSY AWX8725
2..COMPONENT ASSY AWX8726
2..TACT ASSY AWX8730
2..INLET ASSY AWX8731
2..VIDEO BRIDGE ASSY AWX8743
2..AUDIO BRIDGE 1 ASSY AWX8764
2..PFC ASSY AWX8735
1..VOLUME & PREOUT ASSY AWK7956
2..VOLUME ASSY AWX8737
2..PREOUT ASSY AWX8738
2..MULTI CH IN ASSY AWX8739
2..REC SEL ASSY AWX8740
2..POWER SW ASSY AWX8755
2..AUDIO BRIDGE 3 ASSY AWX8767
1..AUDIO INPUT ASSY AWK7958
2..V-AUDIO ASSY AWX8744
2..A-AUDIO ASSY AWX8745
2..IR 232C ASSY AWX8746
2..SUB DIGITAL ASSY AWX8747
1..COMPLEX 1 ASSY AWK7959
2..NEW ITEM ASSY AWX8741
2..DD DSP ASSY AWX8748
2..DD HDMI ASSY AWX8750
2..AUDIO BRIDGE 4 ASSY AWX8766
2..FRONT INPUT ASSY AWX8774
2..FRONT USB ASSY AWX8781
2..DD DISP ASSY AWX8784
2..ICE INPUT 4CH ASSY AWX8946
2..DSP DIODE ASSY AWX8956
2..HDMI DIODE ASSY AWX8957
2..HN DIODE ASSY AWX8958
2..FAN-12V ASSY AWX8959
1..COMPLEX 2 ASSY AWK7960
2..ICE REG ASSY AWX8751
2..FUNC ENCODER ASSY AWX8753
2..VOL ENCODER ASSY AWX8754
2.. PRIMARY ASSY AWX8756
2..A-REG ASSY AWX8761
2..AUDIO BRIDGE 2 ASSY AWX8765
2..DA DIODE ASSY AWX8965
2..ICE 5 ASSY AWX8968
2..ICE 12 ASSY AWX8969
1..MOTHER 1 ASSY AWK7965
2..DIGI BRIDGE ASSY AWX8752
2..MOTHER 1 ASSY AWX8770
2..FRONT BUFF ASSY AWX8775
2..ICE INPUT 6CH ASSY AWX8945
1..MOTHER 2 ASSY AWK7969
2..MOTHER 2 ASSY AWX8776
2..DISPLAY ASSY AWX8777
2..COMPOSITE ASSY AWX8778
2..ICE INTERFACE ASSY AWX8779
2..ICEBLUE ASSY AWX8780
2..PERCH FFC ASSY AWX8782
2..PERCH DISP ASSY AWX8783
2..PERCH PS ASSY AWX8785
1..HDMI ASSY AWQ7038
1..HN MODULE ASSY AWV2535
1..USB ASSY AWX8867
1..DSP ASSY AWX8868
1..2CH DD ASSY AWX8961
>
1..ICEPOWER AMP ASSY AWH7010
>
1..ICEPOWER SMPS ASSY AWR7048
1..5.1 TFT MODULE AWV7006
1..FM/AM TUNER UNIT AXX7250
Mark No. Description Part No.
