Pioneer SC-LX90 User Manual

89
SC-09TX
5
6 7 8
5
6 7 8
A
B
C
D
E
F
REAR SECTION (2/2) PARTS LIST
Mark No. Description Part No.
1 COMPOSITE Assy AWX8778
2 S-VIDEO Assy AWX8725
3 COMPONENT Assy AW X8726
4 VIDEO BRIDGE Assy AWX8743
5
• • • • •
6 IR 232C Assy AWX8746
7 MOTHER 2 Assy AWX8776
8
• • • • •
9 5P FFC (J1924) ADD7569
10 9P FFC (J1925) ADD7581
11 24P FFC (J1927) ADD7589
12 26P FFC (J1928) ADD7590
13 30P FFC (J1929) ADD7591
14 8P FFC (J1930) ADD7616
15 7P Housing Assy (J1937) ADX7644
16 Earth Terminal with Knob AKE-031
17 PCB Spacer AEC7080
18 Screw VPZ30P100FTB
19 Hex. Screw 2.85 x 7 ABA7078
20 Screw BBT30P060FTB
