7
SC-LX90
5
6 7 8
5
6 7 8
A
B
C
D
E
F
(1) EXTERIOR SECTION PARTS LIST
(2) CONTRAST TABLE
SC-LX90/WYPWXJ5, SC-LX90/WVLXJ5 and SC-LX90/LFXJ are constructed the same except for the following:
Mark No. Description Part No.
1 PERCH DISP Assy AWX8783
2 P.Metal B AAP7100
3 Spacer 3.5 x 8 x 50 AEB7381
4 Spacer 4 x 8 x 150 AEB7400
5 Cushion 2 x 13.5 x 73 AED7103
6 Top Plate B ANE7346
NSP 7 Side Angle ANG7555
NSP 8 Beam L ANG7568
NSP 9 Beam S ANG7574
> 10 Ferrite Core (L1948) ATX7009
11 Side Panel BU AAH7126
12 Side Panel BL AAH7130
13 Name Plate See Contrast table (2)
14 Reuse Band AEC7584
15 Screw 3 x 8 ABA7131
16 Spacer 7 x 45 AED7118
17 Duct Cushion AED7115
18 Screw BBZ30P080FTB
19 Screw BBZ30P060FCC
20 Screw VPZ30P100FTB
21 Screw 3 x 10 ABA7134
22 Washer WH30FTC
23 Screw BBT30P060FTB
24 Screw FBN 4 x 10 ABA7143
25 Washer WA42D080D050
26 Gasket (6 x 6 x 25) ANK7141
> 27 Ferrite Core (L1949) ATX7010
28 Shield Sheet D AMR7546
29 Spacer 4 x 8 x 190 AEB7401
30 Spacer 5 x 10 x 70 AEB7402
31 Insulation Sheet D AEC7615
32 Nylon Rivet AEC7408
33 Gasket Holder AED7125
34 Insulation Washer AEC7617
35 Insulation Sheet E AEC7616
36 Screw CBZ30P080FTB
Mark
No. Description Part No.
Mark No. Symbol and Description
SC-LX90/
WYPWXJ5
SC-LX90/
WVLXJ5
SC-LX90/
LFXJ
13 Name Plate AAH7137 AAH7137 AAH7138
To Next Page
